Mobile Vet Anesthesia Machine
HF-1200V8
Main Parameters
|
Working Mode |
Closed,Semi-closed,,semi-open system, Open |
|
Driven mode |
Pneumatically driven manual controlled |
|
Application |
0.5-100kg animal |
|
Anesthesia gas source switch |
start or stop the gas source control |
|
Pressure Gas Gauge |
four press gauge;one is oxygen source pressure,one is oxygen working |
|
Alarm parameter |
Upper tidal volume alarm,low oxygen source pressure,one is oxygen working |
|
High precious anesthesia vaporizer,the agent output is continuous and stable,and precise |
|
|
The agent type |
Isoflurane,Enflurane,halothane,sevoflurane |
|
Oxygen flush |
25L/min~75L/min |
|
Airway pressure |
O2:0.25Mpa~0.65Mpa |
|
Anesthesia Ventilator: |
|
|
Screen |
9 inches touch screen |
|
Respiration mode PCV,VCV,SPONT,MANUAL,DEMO |
|
|
Bellow big animal |
50-1600ml,small animal:0-300ml |
|
Waveform Pressure,Flow,Volume |
|
|
Loop |
P-V,P-F,F-V |
|
Tidal volume |
Auto-control:20-1600ml |
|
Manual control |
5-1600ml |
|
Breathing rate |
1-100bpm |
|
I:E ratio |
9.9:1 to 1:9.9 |
|
Inspiratory time 0.1s-10.0s |
|
|
Inspiratory pause 0-50% |
|
|
PEEP Off,3-20cmH2O |
|
|
Pressure support 5-60cmH2O |
|
|
Flow trigger 0.5-20L/min |
|
|
Pressure trigger -1~20cmH2O |
|
|
Vaporizer: |
|
|
With safety lock |
|
|
Concentration range: |
|
|
Halothane Isoflurane |
0.2 to 5% 0.2 to 5% |
|
Sevoflurane |
0.2 to 8% |
|
Flow rate range |
0.2 to 15L/min |
|
0.2 to 10L/Min (normal application) |
|
|
when concentration>5 vol% |
|
|
Anesthetic volume |
340ML (dry cavity)300ML (wet cavity) |
|
Suspension type |
Selectatec international standard type |
|
Flowmeter: |
|
|
Oxygen nitrous oxide double tube flowmeter |
|
|
Oxygen |
0~10L/min |
|
Nitrous oxide |
0~10L/min |
|
With oxygen nitrous oxide linkage protection device |
|
|
Make sure that the oxygen concentration is no less than 25% |
|
Intelligent Parameter Calculation
The mobile vet anesthesia machine's one-touch setup saves time and effort. Proportional valve control and a high-precision vaporizer ensure precise anesthesia. The dome light optimizes the surgical field of view, and the modular structure facilitates assembly and disassembly for maintenance.
Features
Intelligent and Precise Anesthesia Control
- A high-precision vaporizer minimizes concentration adjustment errors, ensuring stable anesthetic gas delivery
- After entering the animal's weight, the device intelligently calculates the weight and automatically adjusts parameters such as tidal volume and respiratory rate to minimize human error
- A built-in proportional valve control system adapts to the needs of different anesthesia stages
Multi-Scenario Breathing Support
- Various breathing modes meet the needs of surgical and emergency situations
- High-precision sensor monitoring displays real-time airway pressure and flow data to ensure safe ventilation
- The front-mounted small animal port, designed specifically for mice and rabbits, prevents excessive dead space in the circuit from affecting anesthesia effectiveness
User-friendly Design
- 8-inch high-definition touchscreen with a graphical interface that supports sliding to adjust parameters, ensuring smooth operation
- Dome lighting system enhances visibility of the surgical site
What are the advantages of a dual-vapor canister configuration for pet treatment?
This machine is equipped with two independent anesthesia vapor canisters. Clinically, the medication can be flexibly switched according to the animal's size, age, and surgery duration: there is no need to change vapor canisters mid-operation, improving operating room efficiency and adapting to the anesthesia needs of various animals such as cats, dogs, and exotic pets.
What are the advantages of the integrated design with a mobile trolley and storage drawers?
1. The bottom omnidirectional silent wheels with brakes allow for easy movement to the operating table or examination cage, and once fixed, they will not slide, making it suitable for multi-station use in operating rooms;
2. The double-layer enclosed drawers can store breathing tubing, masks, emergency supplies, and testing accessories, keeping the work surface tidy and preventing the loss of instruments;
3. The integrated vertical structure integrates the breathing circuit, flow meter, and monitoring screen, eliminating the need for additional support structures and saving limited treatment space in veterinary hospitals.
Our Advantages
- Multiple transportation and logistics channels (land,sea,air and railway transport), global delivery!
- Quick response mechanism, providing one-stop support for installation and maintenance.
- The product has undergone multi-centre clinical trials and is clinically proven to be reliable.
- Covering all areas including diagnostic equipment, therapeutic equipment, rehabilitation equipment, etc. to meet different clinical needs.
Production process
Sheet metal parts--Warehouse in inspection--Assembly--Wiring--Cooling system--Module installation--Interior cleaning--Machine completing debugging--Inspection--Exterior cleaning--Configure installation--Inspection--Labeling--Finishing product warehouse--Packing--Shipment
